Altimeter
max. altitude: 12’300 m – scale: 1 m or 1 ft
QNH: indication of air pressure in hPa or in inHg
ALT1 – absolute altimeter
ALT2 – absolute- or relative altimeter
ALT3 – differential altimeter
Variometer
Analog display
± 10 m/s – scale: 0,2 m/s over the entire scale range, ± 20 ft/min x 100 scale: 0,4 ft/min x 100
Digital display
± 300 m/s or ft/min x 100 scale: 0,1 m/s or 0,1 ft/min x 100
Integrator
adjustable from 1 sec. up to 30 sec.
Acoustics
volume: 4 audio volume settings
climb acoustic: tone- and interval modulated, maximum interval frequency adjustable from 3 m/s up to 11 m/s or
Smart-interval, adjustable response threshold
sink acoustic: discreet sink tone and loud sink alarm, separately adjustable.
Thermometer
measuring range: - 20 °C up to + 60 °C
display: °C or °F
scale: 0,1 °C or 0,1 °F, can be calibrated 50%
GPS
updaterate of 1 sec., independent from preset recording rate.
Speedometer (sensor optional)
measuring range: 0 km/h up to 120 km/h
display: km/h, kts, or mph
scale: 1 km/h, 1 kt or 1 mph
can be calibrated: ± 50%
Barograph
memory: 50 flights with date, start time, flight time, max. altitude and min./max. Vario, recording time up to 120 hours at 30 sec. recording rate with position, barometric altitude and GPS-altitude, satellite constellation and True Airspeed.
recording interval: adjustable from 1 up to 30 seconds.
PC-connection with USB-1.1 cable. Analysis with Flychart software.
Software
Flychart provides for additional individual settings, e.g. audio pitch, response characteristic, sensitivity etc., flight statistics, flight database, print-out. Firmware update with the Flytec-Flasher tool.
